Back to CatalogDELIXI ELECTRIC Digital Multimeter Backlit Portable High-Precision Universal Meter Electrician Household Ammeter Smart Burn-Proof
Specifications
- Category
- digital multimeter
- Functions
- Resistor, electric current, voltage, Smart NCV
- Measuring range
- Manual range
- testing principles
- true effective value
- Precision
- three and a half
Variants / Sale Attributes
Model: [0801B] Resistance/Continuity/Capacitance
Measuring range: Official standard configuration [bare device + test leads]
Package Contents
Product main body ×1
Product Description
Product Specifications
DLY-0801A (Manual Range)
DLY-0801B (Manual/Auto Range)
DLY-0801C (Auto Range)
Two styles available; shipped randomly; actual product prevails.
High-performance processor with full-range burn protection.
Automatic range selection (for DLY-0801C and DLY-0801B).
Manual and auto range switching (DLY-0801B).
Dual ceramic fuse protection; prevents damage from incorrect range selection.
Soft silicone insulated test leads, 1 meter length, double-layer insulation, flame retardant.
Stainless steel sharp test probes rated at 1000V/10A, high precision and oxidation resistance.
Large 9999 count display for higher precision compared to standard 1999 count meters.
Thick 3.5mm rubber housing for insulation, water, dust, and drop resistance; detachable soft rubber shell.
LCD backlit display with clear readings in low light.
Built-in high-brightness LED flashlight for dark environments.
Automatic power off after 15 minutes of inactivity to save battery.
Data hold function and error indication.
Similar Products
In Stock
In Stock
Audible buzzer for overload warning, continuity testing, and NCV alerts.
Non-contact voltage (NCV) detection with audible and visual alerts.
True RMS measurement for accurate readings regardless of waveform.
VFC (Variable Frequency Control) measurement for frequency and duty cycle.
Line continuity and live/neutral wire detection.
Auto and manual data range hold.
High accuracy and durability guaranteed by DELIXI ELECTRIC, a top 500 Chinese enterprise.
| Function | DLY-0801A (Manual) | DLY-0801B (Manual/Auto) | DLY-0801C (Auto) |
|------------------------|-----------------------------|-------------------------------|-------------------------------|
| DC Voltage | 200mV ~ 600V | 600mV ~ 600V | 99.99mV ~ 600V |
| Resolution | 100μV ~ 1V | 100μV ~ 100mV | 10μV ~ 1V |
| Accuracy | ±(0.5%~0.8% reading + 2 digits) | ±(0.5%~0.8% reading + 5 digits) | ±(0.5% reading + 2 digits) |
| AC Voltage | 200V ~ 600V | 6V ~ 600V | 99.99mV ~ 600V |
| Resolution | 100mV ~ 1V | 1mV ~ 1V | 10μV ~ 1V |
| Accuracy | ±(1.2% reading + 10 digits) | ±(1.0% reading + 3 digits) | ±(1.0%~1.2% reading + 3 digits)|
| DC Current | 2mA ~ 200mA | 600μA ~ 600mA | 999.9μA ~ 600mA |
| Resolution | 1μA ~ 100μA | 0.01μA ~ 100μA | 0.01μA ~ 100μA |
| Accuracy | ±(1%~2.0% reading + 2 digits) | ±(1%~2.0% reading + 2 digits) | ±(1%~2.0% reading + 2 digits) |
| AC Current | Not supported | 600μA ~ 600mA | 999.9μA ~ 600mA |
| Resolution | - | 0.01μA ~ 100μA | 0.01μA ~ 100μA |
| Accuracy | - | ±(1%~2.0% reading + 5 digits) | ±(1%~2.0% reading + 5 digits) |
| Resistance | 200Ω ~ 20MΩ | 60kΩ ~ 60MΩ | 99.99Ω ~ 99.99MΩ |
| Resolution | 0.1Ω ~ 10kΩ | 0.1Ω ~ 10kΩ | 0.1Ω ~ 10kΩ |
| Accuracy | ±(0.8%~1% reading + 2~5 digits) | ±(0.8%~3% reading + 2~5 digits) | ±(0.8%~3% reading + 2~5 digits)|
| Capacitance | Not supported | 6nF ~ 60mF | 9.999nF ~ 99.99mF |
| Resolution | - | 1pF ~ 10μF | 1pF ~ 10μF |
| Accuracy | - | ±(3%~5% reading + 5~10 digits) | ±(3%~5% reading + 10 digits) |
| Frequency | 10Hz ~ 10MHz | 9.999Hz ~ 9.999kHz | 9.999Hz ~ 9.999kHz |
| Accuracy | ±(0.1% reading ± 5 digits) | ±(0.1% reading ± 5 digits) | ±(0.1% reading ± 5 digits) |
| Duty Cycle | Not supported | 10% ~ 95% | 10% ~ 95% |
| Accuracy | - | ±(1.0% reading ± 5 digits) | ±(1.0% reading ± 5 digits) |
| Diode Test | Supported | Supported | Supported |
| Continuity Test | Supported (with buzzer) | Supported (with buzzer) | Supported (with buzzer) |
| Non-Contact Voltage (NCV) | Supported | Supported | Supported |
| VFC (Variable Frequency Control) | Not supported | Supported | Supported |
| True RMS Measurement | Supported | Supported | Supported |
| Live/Neutral Wire Detection | Supported | Supported | Supported |
Additional details
- Size
- 71.5 mm x 41.3 mm x 142 mm
LCD with backlight for clear readings in dark environments.
Data hold and error indication.
Automatic power off after 15 minutes of inactivity.
High-brightness LED flashlight integrated.
Audible buzzer for overload, continuity, and NCV alerts.
Soft silicone insulated test leads with flame retardant and high durability.
Dual ceramic fuse protection for safety.
Rubber housing for shock, dust, and water resistance.
Supports manual and automatic range switching (model dependent).
High accuracy and reliability ensured by DELIXI ELECTRIC quality standards.
DELIXI ELECTRIC Multimeter (model as ordered)
Actual product appearance may vary due to design updates.
For detailed measurement parameters and instructions, please refer to the user manual.
