Available in 200 mm and 320 mm lengths for various tripods without center columns
Compatibility
Center column diameter corresponds to tripod leg diameter (e.g., DC-282C for 28 mm maximum leg diameter)
Height Reference
With 2-section center column installed, maximum height is Approx. 1.7 m; with 2-section center column, maximum height is 1.6 m; with 1-section center column, maximum height is 1.48 m; tripod fully extended, maximum height is 1.28 m
Specifications
Item
Detail
Models
DC-222C, DC-252C, DC-282C, DC-322C
Tube Diameters
22/19 mm, 25/22 mm, 28/25 mm, 32/28 mm
Weights
100 g, 118 g, 143 g, 184 g
Height Range
200-320 mm for all models
Load Capacity
8 kg, 12 kg, 16 kg, 20 kg
Base Diameter
29 mm, 34 mm, 38 mm, 48 mm
Details
Silicon rubber pads for anti-pinch design
1/4" and 3/8" mounting screws
Widened base with 3/8" universal screw hole
10-layer carbon fiber tubes for high strength and low weight
Integrated gaskets for increased durability and reliability
Some details may vary based on specific model variations.
