Ruijie 300M Elevator-Specific Bridge RG-YST250F Pair, Outdoor Security Monitoring Video Return, Factory-Installed 500-Meter Transmission, Label Fluorescent, IP55 Protectio

CN¥392.40

SKU: 100075899606

Status:In Stock (2)

ID: 100074386015

Weight: 810.00 g

Dims:208x205x82 mm

Antenna: Built-in antenna
Wireless speed: 300M
Management method: App management, Web Page, Remote Management, Cloud Management
Total carrying capacity: <30 terminals
Game Acceleration: No
WAN port: 100 megabit Ethernet port
Coverage: 201-300m2
Cooling method: Natural heat dissipation

Color: RG-YST250F Pair, Elevator Network Bridge 500 Meters

1 RG-EST350 V2 video recorder unit; 1 RG-EST350 V2 camera unit; 2 24V/0.5A non-standard PoE adapters; 2 adapter power cables; 1 product manual

Product Description

Out of Stock

MERCURYData communication network equipment

WiFi7 | 3600M | 3600HP Series

CN¥389.00

In Stock

TP-LINKData communication network equipment

Single | Dual 2.5G | TL7AP3622HIPoE

CN¥539.00

Wireless protocols

Wi-Fi 5

LAN output port

100 megabit Ethernet port

WAN port type

Electrical port

LAN port type

Electrical port

Stability: Designed for stable monitoring even with multiple elevators running simultaneously
Interference Resistance: Supports anti-interference mode to reduce mutual interference between network bridges and ensure stable monitoring operation
Protection: Dust-proof, waterproof, high protection for outdoor scenarios

Item	Detail
RF Design	Dual-stream single-frequency 2x2
Operating Frequency	2.4GHz
Standard	802.11b/g/n
Antenna Type	Built-in directional antenna, 70° horizontal, 70° vertical
Bridge Distance	Recommended 500 meters
Spatial Streams	2 streams
Transmission Rate	Up to 300Mbps wireless bridge negotiation rate at 2.4GHz
Transmit Power	≤125mW

Automatic bridging function: Supports automatic pairing between the recorder end and the camera end
QR Code Login: Scan the device QR code to log in to the device configuration interface
Configuration Methods: Supports APP/Web configuration modes and synchronization
Broadcast Multicast Acceleration: Supported
