Huawei Kunling S5735S-L48P4S-A3 48-Port Gigabit Managed Layer 3 PoE Switch with 4 Gigabit SFP Ports, VLAN, Ring Network, 380W Power

Supports automatic MAC address learning and aging

Maximum 16K MAC entries

Supports static, dynamic, and blackhole MAC entries

Source MAC address filtering and interface MAC learning limit

Supports up to 4K VLANs

Supports Voice VLAN, MUX VLAN, VLAN stacking, VLAN mapping

Supports LNP, VCMP, GVRP protocols

Supports SmartLink tree topology and multi-instance

Millisecond-level primary/backup link protection

Supports ERPS (G.8032)

Supports STP (IEEE802.1d), RSTP (IEEE802.1w), MSTP (IEEE802.1s)

Supports BPDU protection, root protection, loop protection, BPDUTunnel, SEP protocol

Supports LBDT, L2PT, DLDP, SmartLink, MonitorLink

Supports 802.1ag, 802.3ah, Y.1731

Supports PIM-DM, PIM-SM, PIM-SSM

Supports IGMP v1/v2/v3, IGMP snooping, MLD snooping

Supports multicast load balancing on bundled ports

Supports port-based multicast traffic statistics, VLAN multicast, static multicast MAC

Supports static routing, routing policies, policy routing

Supports RIP, RIPng, OSPFv2, OSPFv3, VRRPv4, VRRP6

Maximum 4096 IPv4 FIB entries, 1024 IPv6 FIB entries

Supports Neighbor Discovery (ND), PMTU

Supports IPv6 Ping, Traceroute, Telnet

Supports LACP, VRRP, BFD, LLDP

Supports ingress and egress rate limiting per port

Supports packet redirection, port-based traffic policing

Supports dual-rate three-color CAR

Each port supports 8 queues with DRR, SP, DRR+SP scheduling

Supports 802.1p and DSCP priority remarking

Supports Layer 2 to Layer 4 packet filtering by MAC, IP, TCP/UDP ports, protocol, VLAN

Supports queue rate limiting and port shaping

Supports VLAN slicing

User hierarchical management and password protection

DOS and ARP attack prevention, ICMP attack protection

Supports IP, MAC, port, VLAN binding

Supports port isolation, port security, Sticky MAC

Supports blackhole MAC addresses and MAC learning limits

Supports IEEE 802.1X authentication, single port max user limit

Supports Portal authentication, AAA, Radius, HWTACACS, NAC

Supports SSH v2.0, HTTPS, CPU protection

Supports blacklist and whitelist

Supports DHCP client, relay, server, snooping; DHCPv6 client and relay

Supports intelligent stacking iStack, fast stack upgrade

Supports Netconf/Yang cloud management

Supports Virtual Cable Test

Supports Telnet remote configuration and maintenance

Supports SNMP v1/v2/v3, RMON

Supports eSight network management system, Web management, HTTPS

Supports LLDP/LLDP-MED

Supports system logs, hierarchical alarms

Supports IEEE 802.3az Energy Efficient Ethernet (EEE)

Supports IFIT, port mirroring, registration center startup

Supports sFlow, NQA, Telemetry

Supports VBST based on VLAN Spanning Tree Protocol (compatible with PVST/PVST+/RPVST)

S5735S-L-A3 series switches offer 8/24/48 full Gigabit models (PoE and non-PoE) to meet diverse networking needs

Suitable for large and medium campus access, small network core deployment

Provides diverse desktop access functions for fast construction of high-performance Gigabit-to-desktop networks
