HIKMICRO Thermal Imager HD Infrared Thermal Imaging Temperature Measurement Night Vision Floor Heating Inspection Leak Detection E09SE

HIKMICRO•Infrared thermal imager

HIKMICRO Thermal Imager HD Infrared Thermal Imaging Temperature Measurement Night Vision Floor Heating Inspection Leak Detection E09SE

CN¥749.00

SKU: 100270780402

Status:Out of Stock

ID: 100067351726

Weight: 740.00 g

Dims:340x220x90 mm

Specifications

Category: Handheld
Suitable Scenarios: Power inspection, repair, Industry, leak test, military, firefighting, scientific research, Outdoor
work shift: Long wave

Variants / Sale Attributes

Model: [Best Seller TOP 1] E09SE (Hot Image 240*240)

Package Contents

Instruments, chargers, warranty, user manual

Product Description

Product Specifications

Overview

Brand: HIKMICRO
Model: E09Se

Newly upgraded core functionality for industrial temperature measurement

Additional details

High-resolution ISR (Super Resolution) imaging: 192×192 pixels (36,864 pixels)
Thermal sensor: Uncooled Vanadium Oxide Microbolometer
Detector resolution: 96×96 pixels (9,216 pixels)
NETD (Noise Equivalent Temperature Difference)

Similar Products

In Stock

HIKMICRO Thermal Imaging Camera, High-Definition Infrared Thermal Imager, Industrial Temperature Measurement, Power Inspection, Underfloor Heating Leak Detection Device H13PRO

HIKMICROInfrared thermal imager

HIKMICRO Thermal Imaging Camera, High-Definition Infrared Thermal Imager, Industrial Temperature Measurement, Power Inspection, Underfloor Heating Leak Detection Device H13PRO

[Touchscreen Model] H13Pro (Pixel 192*144/digital Zoom/photography And Video Recording)

CN¥4,699.00

In Stock

FLUKE TC01A Smartphone Thermal Imager, Thermal Imaging Night Vision Device, Infrared Thermometer, High-Definition Thermal Imager

FLUKEInfrared thermal imager

FLUKE TC01A Smartphone Thermal Imager, Thermal Imaging Night Vision Device, Infrared Thermometer, High-Definition Thermal Imager

TC01A - Supports Android System

CN¥2,536.00

<50mK (@25°C, F#=1.0)

Minimum imaging distance

0.1 m

Field of view (FOV)

50°×50°

Frame rate

25Hz

Spatial resolution (IFOV)

8.89 mrad

Thermal lens focal length

1.35 mm

Visible light camera resolution

640×480 pixels

Thermal image resolution

240×240 pixels

Display

2.4-inch LCD screen (320×240 pixels)

Image display modes

Thermal imaging with multiple pseudo color modes including White Hot, Black Hot, Iron Red, Rainbow, Red Hot, Fusion, Blue-Yellow

Image format

JPEG with embedded temperature data

Focus

Fixed focus (no adjustment required)

Mounting

Tripod mount UNC14-20

Temperature measurement range

-20°C to 550°C

Temperature accuracy

±2°C or ±2% of reading (whichever is greater)

Adjustable emissivity

0.01 to 1.00 for different materials (e.g., 0.96 for printing circuit boards, 0.91 for cement concrete, 0.92 for ceramics, 0.95 for rubber)

High and low temperature tracking with automatic detection of center, maximum, and minimum temperature points for efficient hotspot identification

Alarm settings with temperature threshold alerts and on-screen temperature warnings

Supports offline client analysis software (PC Analyzer) with professional thermal imaging analysis and report export capabilities

Supports multiple pseudo color modes for enhanced detail visualization

Supports photo capture and video recording with embedded temperature data

Intelligent screencasting (UVC projection supported)

Additional details

Internal storage: 4GB built-in eMMC
Storage expansion: Not supported
Hardware interface: Type-C port for charging and data transfer
Charging time: Less than 3 hours at 25°C
Battery: Rechargeable lithium battery with over 8 hours of continuous operation at 25°C
Bluetooth: Not supported
Wi-Fi: Not supported
Lighting: Not supported
Operating temperature and humidity: 10°C to 50°C, ≤95% RH
Storage temperature and humidity: -40°C to 70°C, ≤95% RH
Protection rating: IP54 (dust and splash resistant)
Drop resistance: 1 meter
Electromagnetic compatibility (EMC): Complies with GB/T17799.2, GB17799.3-2012
Shock and vibration resistance: Complies with GB/T2423.5-2019, GB/T2423.10-2008
Dimensions: 196 mm × 117 mm × 59 mm
Weight: 240 g

Thermal imaging device E09Se

Additional details

Factory calibration certificate (Serial No.: E1)

User manual

Blister packaging

Data cable

IEC61010 certified

Supports real-time temperature data display and quick identification of abnormal hotspots to avoid missed detections

Supports multiple pseudo color modes for detailed target presentation and precise user analysis

Supports on-device photo and video capture for documentation and review
