HSD Pneumatic Spray Gun Automotive Sheet Metal High Atomization Spray Pot Primer Spray Gun W-77-1G Upper Pot 2.0mm Black Gun

•Other manual tools

HSD Pneumatic Spray Gun Automotive Sheet Metal High Atomization Spray Pot Primer Spray Gun W-77-1G Upper Pot 2.0mm Black Gun

CN¥88.00

SKU: 100343483606

Status:In Stock (8)

ID: 100063344400

Weight: 560.00 g

Dims:212x138x122 mm

Specifications

Customizable or not: Not customizable
Category: Spray gun

Variants / Sale Attributes

Style: W771G Upper Pot 2.0 Caliber Black Gun [Jingpei]

Package Contents

Pneumatic spray gun *1

Product Description

Product Specifications

Overview

Brand: HSDC (Haiseidike)

Suitable for a wide range of scenarios including furniture spraying, metal crafts, plastic products, woodworking spray painting, automotive repair, and model graffiti.

Made of high-quality alloy steel material, resistant to rust, wear-resistant, and durable.

Long-lasting use and flexible operation.

Additional details

Two types of paint cups: upper cup and lower cup, both with consistent atomization effects.
Upper cup: Suitable for spraying high places (above user height, ceilings, dead corners, small angles, hard-to-reach areas); cup can rotate 360° for flexible adjustment.
Lower cup

Similar Products

Out of Stock

ANCHOR Multifunctional Punching Woodworking Electric Drill Alloy Bit Set 8cm Woodworking Drill 5 Pieces

ANCHOROther manual tools

ANCHOR Multifunctional Punching Woodworking Electric Drill Alloy Bit Set 8cm Woodworking Drill 5 Pieces

Carpentry drill bits (set of five, flexible)

CN¥10.00

In Stock

HSD Pneumatic Spray Gun Automotive Sheet Metal High Atomization Spray Pot Primer Spray Gun K-3 Top Cup 0.5mm Nozzle

Other manual tools

HSD Pneumatic Spray Gun Automotive Sheet Metal High Atomization Spray Pot Primer Spray Gun K-3 Top Cup 0.5mm Nozzle

K3 Upper Pot 0.5 Caliber [Jingpei]

CN¥49.20

In Stock

Lekali Electric Drill to Reciprocating Saw Conversion Head Household Small Electric Saw Handheld Woodworking Saber Saw

Other manual tools

Lekali Electric Drill to Reciprocating Saw Conversion Head Household Small Electric Saw Handheld Woodworking Saber Saw

Electric drill to electric saw adapter + 6 saw blades

CN¥39.84

Suitable for long-duration work with larger capacity but may have residue due to incomplete suction at the bottom.

Multiple models and nozzle diameters available.

Paint cup capacities vary by model

Item	Detail
Upper cup G capacity	400ml, nozzle diameters same as lower cup S.
Lower cup S capacity	400ml or 1000ml depending on model.

1. Lower cup S for horizontal spraying or within ±45° angle

Item	Detail
W-77-1G	2.0 mm nozzle, 400ml capacity
W-77-2G	2.5 mm nozzle, 400ml capacity

2. Upper cup G with 360° rotation

Item	Detail
W-77-1S	2.0 mm nozzle, 1000ml capacity
W-77-2S	2.5 mm nozzle, 1000ml capacity

Additional details

3. PQ-2: 2.0 mm nozzle, 1000ml capacity (lower cup only)
4. K-3: 0.5 mm nozzle, 120ml capacity (upper cup only)

Use nozzle diameter 1.8mm or above for primer spraying.

Use nozzle diameter 1.5mm or below for topcoat spraying.

Portable hook for hanging

Spray width adjustment

Paint output adjustment

Flow cap and nozzle

Valve switch

Material inlet connector

Trigger

Connection nut

Air inlet connector

Paint cup

Air volume adjustment

1. Pour the pre-mixed paint into the paint cup and connect to the material inlet.

2. Connect compressed air to the air inlet.

3. Pull the trigger and adjust working air pressure between 3.5-4.5 bar.

4. Adjust paint output and spray width as needed.

5. Spray on clean surfaces with parallel and vertical strokes at approximately 20 cm distance.

Additional details

Dimensions: Width 6 cm, Height 9 cm, Length 16 cm
Weight: 0.31 kg

Features

Single paint cup
Air pressure adjustment
Flow adjustment
Spray cap
Quick wrench
Air inlet

Additional details

Model: K-3
Nozzle diameter: 2.0 mm
Length: 23 cm
Weight: 0.79 kg
Packaging: Neutral color cardboard box
Package size: 23 x 13 x 12 cm
Model: PQ-2

High hardness alloy nozzle

Integrated high-speed air channel for stable and smooth air transmission
