Caipu Colorimeter High-Precision Portable Colorimeter DS100E Color Matching Card Number Database Universal Colorimeter

•Colorimeter

Caipu Colorimeter High-Precision Portable Colorimeter DS100E Color Matching Card Number Database Universal Colorimeter

CN¥399.00

SKU: 100073587138

Status:In Stock (9)

ID: 100073587138

Weight: 780.00 g

Dims:304x172x100 mm

Specifications

Sensor type: Spectrophotometry
Category: Portable colorimeter

Variants / Sale Attributes

Model: DS100

Package Contents

Colorimeter*1 Third-party key laboratory calibration report*1 Instruction manual*1

Product Description

Product Specifications – CaiPu DS Series Spectrophotometers

Overview

Brand: CaiPu
Models: DS-100, DS-200, DS-210, DS-220
All models: D/8 geometry with SCI (Specular Component Included)
D/8: Measurement aperture at 8° from sample normal; light diffusely reflected inside an integrating sphere; specular reflection included for color attribute analysis independent of surface gloss.
DS-100 & DS-200: CIE-Lab, Spectral Reflectance

Similar Products

In Stock

3nhColorimeter

3Nh Portable Handheld High-Precision Colorimeter NR10QC, Ink Coating Plastic, Entry-Level Practical Color Difference Detector

NR10QC (4MM Diameter)

CN¥1,970.00

View

Out of Stock

Colorimeter

Caipu Colorimeter High-Precision Plastic Paint Powder Color Tester Portable Handheld Colorimeter DS01

DS-01

CN¥260.00

View

Out of Stock

Colorimeter

Linshang Bluetooth Touchscreen Colorimeter LS173 Hardware Paint Plastic Metal Surface Color Difference Meter Colorimeter

LS173 (Bluetooth Touchscreen Model) Painted Plastic Metal

CN¥980.00

View

CIE-Lab, CIE-LCh, HunterLab, ΔE*ab, CIE-Luv, XYZ, Yxy, RGB, Color Differences (ΔE*ab, ΔE*cmc, ΔE*94, ΔE*00), Whiteness (ASTM E313-00, ASTM E313-73, CIE/ISO, AATCC, Hunter, TaubeBergerStensby), Yellowness (ASTM D1925, ASTM E313-00, ASTM E313-73), Blackness (My, dM), Color Fastness, Tint (ASTM E313-00), Color Density CMYK (A, T, E, M), Metamerism Index (Milm), Munsell, Opacity, Dye Strength.

DS-100

2 apertures, Ø11 mm

DS-200

2 apertures, Ø6 mm

DS-210

4 apertures, Ø11 mm and Ø6 mm

DS-220

6 apertures, Ø11 mm, Ø6 mm, and Ø3 mm

DS-100, DS-200, DS-210

LED full-spectrum balanced light source

DS-220

LED full-spectrum + UV light source (for fluorescent material measurement)

400 nm to 700 nm, 10 nm intervals

Additional details

Accuracy: 0.01 ΔE*ab
Repeatability: ≤0.03 ΔE*ab
Inter-instrument agreement: ≤0.4 ΔE*ab

Approximately 1 second per measurement

Average measurement (2 to 99 times)

DS-210 and DS-220 include camera for visual positioning of measurement area

Additional details

DS-100 and DS-200: visual observation only

0% to 200% reflectance

Additional details

Resolution: 0.01%

D65 standard illumination by default

Additional details

Supports multiple illuminants: A, B, C, D50, D55, D65, D75, F1-F12, CWF, U30, U35, DLF, NBF, T3, TL84, ID5, LED-RGB1, LED-V1, LED-V2

CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO 7724-1, ASTM E1164, DIN 5033 Teil 7

10° standard; also supports 2° and 10° viewing angles

IPS full-color screen, 2.4 inches

Additional details

Battery capacity: 3.7 V / 3000 mAh
Continuous measurement capacity per charge: approx. 8000 times
Light source lifespan: 10 years or 1 million measurements

Additional details

DS-100 & DS-200: Manual calibration
DS-210 & DS-220: Intelligent automatic calibration

Android, iOS, Windows

Data sharing across PC software, mobile app, and mini program with single account login

Nano-integrated spectrometer device

Additional details

Detector: Silicon photodiode array, dual 16 groups
Integrating sphere diameter: 40 mm
Instrument: 100 standard samples, 10,000 test samples
App: Cloud storage with massive capacity, multi-device data sharing

Supports measurement of fluorescent materials (DS-220 with UV light source)

Additional details

Multiple operation modes: standalone, app-based, PC-connected

Printable data reports with customizable parameters

Cloud database for color libraries and sample management

Supports color difference evaluation, color matching, and color library creation

Compatible with HarmonyOS devices

Quality control, color difference detection, color matching assistance, color library establishment

Suitable for products with flat surfaces (DS-100, DS-200)

Suitable for textured surfaces and detailed area measurement with camera (DS-210, DS-220)

DS-220 ideal for various sizes and fluorescent materials

High-tech enterprise certification

Awards from China Instrument and Control Society

Participation in national and industry standard development (GB, JJF, QB standards)

Exhibited at international coatings, plastics, and colorant industry events

Hosts technical seminars and workshops

The CaiPu DS Series spectrophotometers offer high-precision color measurement with consistent accuracy (0.01 ΔE*ab) across models. Differences lie mainly in measurement apertures, presence of camera for positioning, UV light source for fluorescence measurement, and calibration methods. The DS-100 and DS-200 are optimized for flat surface measurements with smaller apertures, while DS-210 and DS-220 provide enhanced functionality including camera-assisted positioning and UV measurement for fluorescent materials. The devices support comprehensive colorimetric parameters, multiple illuminants, and extensive software integration for versatile color management solutions across industries.
